TVNA

Vector Network Analyzer Control Software

Bird’s TVNA Software delivers full-featured control and advanced analysis for the BNA100 and BNA1000 Series Vector Network Analyzers. Connecting via USB, it provides a powerful yet intuitive interface that simplifies even the most complex RF measurements—giving engineers the clarity and control they need.

Key Features

• Streamlined User Interface – Familiar workflows make setup, measurement, and analysis simple for engineers experienced with modern VNAs.
• Flexible Measurement Options – Run a wide range of RF measurements with specialty tools including limit testing, time-domain analysis, and fixture simulation.
• Versatile Trace Formats – Display results in multiple formats: Log Mag, Linear Magnitude, SWR, Phase (Deg & Rad), Group Delay, Real, Imaginary, Unwrapped Phase, Positive Phase, Smith Chart, and Polar plots.
• Powerful Visualization – View up to 16 independent channels at once, with support for 16 traces per channel and 16 markers per trace.
• Advanced Analysis Tools – Expand capabilities with optional Time Domain Analysis & Gating and Fixture Circuit Simulation.

Software Versions

Standard TVNA

• Supports control of a single Bird VNA
• Includes core measurement and visualization tools
• Expandable with advanced analysis options

Multi-Unit TVNA

• Supports up to 4 Bird VNAs simultaneously
• Enables up to 16 VNA channels in one interface
• Designed for complex or parallel test environments

Note: Only one version of TVNA can be installed on a system at a time.

System Requirements

• Windows 7 or later
• 1.5 GHz CPU or higher
• 1 GB RAM minimum
• USB 2.0 interface
